Comfort REP2224S articulated arm operator for swing gates up to 2.3 m without encoder
Articulated arm operator for swing gates up to 2.3 m: 24 V-DC motor, 120 Nm, 120°, without encoder.
SKU
178497
4062434011287
Note
Product added to cart.
Loading...
Comfort REP2224S articulated arm operator for swing gates up to 2.3 m without encoder
Scope of delivery:
- Motor unit without control and without cable (2x1.5 mm² required)
Operator – Features:
- Current-dependent obstacle detection - no active closing edge protection necessary
- Intergrated mechanical stops OPEN and CLOSED
- Very quiet mechanism
- All mechanical parts protected against weather influences
- Sturdy die-cast aluminum housing and UV-resistant plastic covers
- Ideal for narrow columns with little installation space
- Compact shape and quiet movement
- Swing gate operator with articulated arm, designed for swing gates made of aluminum, PVC or wooden leaves
- Battery backup can be integrated in the housing
Comfort REP2224S
Product descriptive data
Number of gate wings
1-leaf
Comfort REP2224
Product descriptive data
Connection type
Conventional
Continuous sound pressure level (max.) [dB(A)]
70
Encoder
No
Protection class
IP44
Application area
Width gate wing (max.) [m]
2.3
Weight of gate leaf (max.) [kg]
250
Height gate wing (max.) [m]
2
Gradient (max.) [%]
0
E dimension (min./max.) [mm]
0/200
Temperature (min./max.) [°C]
-20/55
Performance data
Output torque [Nm]
120
Operating mode (duty cycle)
S2 - 8 min
Opening angle (max.) [°]
120
Motor power [kW]
0.12
Electrical data
Operating voltage [V]
24 V-DC
Operating voltage type
Direct current
Motor voltage [V]
24 V-DC
Rated current [A]
0.6
Dimensions and weights
Weight [kg]
8
Dimensions (WxHxD) [mm]
125x310x260
Dimensions (WxHxDmin/Tmax) [mm]
125x310x260/260
