CS 320 in standard 400V housing (CEE plug) with built-in main switch

Comfort-automatic control.
SKU
185656
4062434014141
CS 320 in standard 400V housing (CEE plug) with built-in main switch

Scope of delivery:

  • Steuerung CS 320 400 V/3~ mit LC-Display im CS-Standardgehäuse, 3-fach-Taster und Hauptschalter im Deckel, 1.000 mm Kabel und CEE-Stecker 5-polig

Functions:

  • 4 programmable relay outputs with 44 functions
  • 2 programmable inputs with 27 functions
  • Changing the direction of rotation via platinum pushbutton/display
  • Intermediate position programmable (only with AWG)
  • Adjustable force limit in OPEN direction (only with AWG)
  • Rotation direction monitoring and detection (only with AWG)
  • Integrated gate run counter
  • Programmable maintenance alarm (PIN code protected)
  • Integrated error memory (readout of all error messages indicating frequency and cycle of last occurrence) only with LCD monitor

End position setting:

  • Via mechanical limit switches (MEC) and/or via absolute encoders (AWG)
  • Setting via platinum pushbutton or plug-in LCD monitor

Operation:

  • Platinum pushbuttons and LEDs for status indication (standard)
  • Pluggable LC display with plain text display
  • 3-button navigation/status and diagnostic messages

Structure and connection:

  • Switchable transformer from 230 V/1~/3~ to 400 V/3~
  • Short-circuit proof extra-low voltage
  • Illuminated cover keypad (night illumination)
  • Housing protection for printed circuit board
  • Adjustable, preassembled wall brackets
  • Connection for elements of the safety circuit
  • Connection for closing edge protection (opto, 8.2 kOhm, pressure wave bar or leading light barrier) in CLOSE direction
  • Connection for closing edge protection (8.2 kOhm and opto) in OPEN direction
  • Connection for 2 light barriers (2-wire, relay, NPN, PNP) with/without testing
  • Connection for wicket door and slack rope switch PL c cat. 2 (8.2 kOhm) with testing according to EN 12453:2017
  • Connection for 2 light grid systems with/without testing
  • Connection for radar presence detector
  • Interface for connecting a frequency inverter
  • Interface for connecting expansion modules
  • Slots for radio module and weekly timer
  • Slot for 2-channel radio transmission system for wireless signal transmission of closing edge system and/or safety circuit
  • Control of the magnetic brake via relay output
  • For operators with externally switched brake, a brake monitoring module is additionally installed (BWM1)
  • Supply for external devices (24 V-DC/500 mA and 230 V-AC/1 A)

Optional:

  • LCD monitor with plain text display
  • MS-Bus extension module two-way traffic control
  • MS-Bus extension module retract protection
  • Integrated main switch
  • Customized cover foils
  • Control in steel cabinet
  • A second CS 320 can be coupled via MS-BUS in DUO function
CS 320 2,2 kW
Product descriptive data
Housing type CS Standard
Protection class IP65
Display type LCD
Main switch in the control cover Main switch 4-pole
Pushbutton in the control cover Electronic 3-series pushbutton CS
Emergency stop in the control cover Without emergency stop
Function switch in the control cover Without function switch
Power plug CEE plug 5-poles. red
Application area
Temperature (min./max.) [°C] -10/45
Performance data
Operating mode (control) Deadman
Electrical data
On-site fuse protection (mains operation 230 V /1~) [A] 10
On-site supply 230 V/1~/50 Hz 230 V/3~/50 Hz 400 V/3~/50 Hz
Load capacity Power (max.) [kW] 2.2
Switching current (max.) [A] 8
Control voltage [V] 24 V-DC
Dimensions and weights
Dimensions (WxHxD) [mm] 215x275x190
