Functions:

• Speed-independent control of gates
• Start and end speed separately adjustable for both running directions
• Additionally 2nd final speed adjustable in running direction CLOSE
• Acceleration and deceleration times adjustable for both directions
• Acceleration and deceleration times for actuation of travel command, stop command, closing edge safety device and light barrier can each be set separately
• Braking points freely selectable/adjustable braking deceleration
• Adjustable power values for adaptation to the motor
• 4 programmable relay outputs with 44 functions
• 2 programmable inputs with 27 functions
• Rotation direction monitoring and detection (only with AWG)
• Integrated gate run counter
• Programmable maintenance alarm (PIN code protected)
• Integrated error memory (readout of all error messages indicating frequency and cycle of last occurrence) only with LCD monitor
• Changing the direction of rotation via circuit board push button/display
• Adjustable power limitation in OPEN direction (only with AWG)
• Intermediate position programmable (only with AWG)

End position setting:

• Via mechanical limit switches (MEC) and/or via absolute encoders (AWG)
• Setting via LC monitor

Operation:

• Circuit board push buttons and LEDs for status indication (standard)
• Pluggable LC display with plain text display
• 3-button navigation/status and diagnostic messages

Structure and connection:

• Short-circuit proof extra-low voltage
• Supply for external devices (24 V-DC/500 mA and 230 V-AC/1 A)
• Illuminated cover keypad (night illumination)
• Housing protection for printed circuit board
• Adjustable, preassembled wall brackets
• Connection for elements of the safety circuit
• Connection for closing edge protection (opto, 8.2 kOhm, pressure wave bar or leading light barrier) in CLOSE direction
• Connection for closing edge protection (8.2 kOhm and opto) in OPEN direction
• Connection for 2 light barriers (2-wire, relay, NPN, PNP) with/without testing
• Connection for wicket door and slack rope switch PL c cat. 2 (8.2 kOhm) with testing according to EN 12453:2017
• Connection for 2 light grid systems with/without testing
• Interface for connecting expansion modules
• Slots for radio module and weekly timer
• Slot for 2-channel radio transmission system for wireless signal transmission of closing edge system and/or safety circuit
• Control of the magnetic brake via relay output
• For operators with externally switched brake, a brake monitoring module is additionally installed (BWM1)
• Interface for connecting a frequency converter
• Switchable transformer from 230 V/1~/3~ to 400 V/3~
• Pluggable LC display with plain text display

Optional:

• MS-Bus extension module two-way traffic control
• MS-Bus extension module pull-in safety device
• Integrated main switch
• Customized cover lamination
• Frequency converter integrated in operator (FU-I version without brake, only 0.75 kW)
• Control in steel cabinet
