MDF 05-14-12

The operators of the MDF series are suitable for 3-phase current (3-phase alternating current) and, with a complete series from 100 to 2000 Nm in this range, offer the right solution for every on-site situation. In addition, special solutions for individual customer requirements can be realized flexibly and quickly at any time..
SKU
P5939
Available in many variants
MDF 05-14-12

Features:

  • Rolled worm shaft
  • Emergency operation via emergency hand crank "KU" (1-sided) or "KU-KU" (2-sided up to 420 Nm & 12 rpm) or emergency hand chain "KE
  • Easy conversion from crank to chain
  • Integrated safety catch, independent of position and speed, maintenance- and wear-free, integrated cushioning
  • Pendulum foot support
  • Supply: 230/400 V/3~/50 Hz
  • Thermal protection in the motor winding
  • For gate systems with above-average circuits, a operator with an increased motor duty cycle (HD) should be selected
  • Pluggable connectors
  • End position setting via electronic absolute encoder (AWG) or mechanical limit switches (MEC)
  • Version with external control, can be combined with extensive control program. Supply: 230/400 V/3~, frequency: 50/60 Hz and control voltage: 24 V-DC
  • When the output speed is increased (operation with frequency converter), the output torque is reduced. In this case, the following applies: An increase of the output speed by 10 % causes a reduction of the output torque by 5 %.
  • Special variants such as other voltages and frequencies, different output speeds, higher degrees of protection and hollow shaft Ø on request
  • ATEX version available (see chapter "Operators for hazardous areas")
  • For temperature ranges below -20 °C there is suitable oil and electric heating on request
MDF 05-14-12
Product descriptive data
Connection type Pluggable
Continuous sound pressure level (max.) [dB(A)] 70
End position system Absolute encoder Mechanical limit switches
Safety catch integrated Yes
Foot attachment type Pendulum foot support
Gearbox Rolled worm shaft Double bearing worm shaft
Emergency operation Emergency hand crank (KU) Emergency hand chain (KE)
Protection class IP54
Overload protection Thermal protection 140 °C
Application area
Temperature (min./max.) [°C] -20/60
Operation with CS 320 FU (frequency converter 230 V/1~) 0,75 kW
Performance data
Output torque [Nm] 140
Output speed [1/min] 12
Torque of the safety catch (max.) [Nm] 309
Output revolutions (max.)** 13
Cycles per hour (max.)* 20
Motor power [kW] 0.45
Electrical data
Operating voltage [V] 400 V/3~ 230 V/3~
Operating voltage type Three-phase current
Power factor cos phi 0.72
Nominal frequency [Hz] 50
Control voltage [V] 24 V-DC
Rated current in star connection [A] 1.90
Rated current in delta connection [A] 3.30
On-site fuse protection (mains operation 230 V/3~) [A] 16
On-site fuse protection (mains operation 400 V/3~) [A] 16
On-site fuse protection (FI operation 400V/3~) [A] 16
On-site fuse protection (frequency converter operation 230V/1~) [A] 16
Dimensions and weights
Weight [kg] 16
Dimension A1 [mm] 100
Dimension B - KE [mm] 191
Dimension B - KU [mm] 108
Dimension C1 [mm] 85
Dimension C - KE [mm] 428
Dimension C - KU [mm] 386
Shaft support [mm] 30
Dimension A - KE [mm] 290
Dimension A - KU [mm] 290

* The values given were determined for an even distribution of the cycles. A cycle consists of two movements (opening and closing) and has a deflection of 10 revolutions of the output shaft in each direction. At ambient temperatures between 40°C and 60°C, a reduction of the maximum cycles per hour by 50% must be taken into account.

** For vertically moving doors and roller shutters, a reduction of the specified pull force by a further 20% may be necessary. Possible reasons for this are, for example, additional seals, double-walled profiles or an unfavorable winding ratio where the door height exceeds the door width. In addition, it should be noted that the maximum torque only occurs after one to two revolutions when thick or high profiles are used.

*** Alternative limit switch ratios are available upon request.
