Digital 991 module receiver with open collector output, 433 MHz bi.linked

Module receiver with 200 memory locations and 1 open collector output, 24 V, unidirectional, 433 MHz bi.linked. For CS 320. For other makes (in conjunction with the enclosed connection cable).
SKU
118727
4062434015377
Digital 991 module receiver with open collector output, 433 MHz bi.linked

Scope of delivery:

  • Universalempfänger
  • Verbindungskabel, 300 mm

Features:

  • 1 channel for free assignment
  • 1 potential-free relay contact for switching an electrical device, e.g. pulse input of a gate control system
  • IMPULSE function
  • Generous memory for up to 200 keys
  • Compact size
Digital 991
Product descriptive data
Connection type Conventional
Antenna Wire antenna
Number of memory locations 200
Outputs

1 Open collector output (PNP)
Color RAL 7011
Radio frequency 433 MHz
Radio technology bi.linked
Channels 1
Communication direction Unidirectional
Contact type 1 NO
Protection class IP00
Radio coding Marantec
Application area
Temperature (min./max.) [°C] -20/60
Electrical data
Operating voltage [V] 12-24 V-DC
Operating voltage type Direct current
Power consumption [VA/W/kW] 0.65 W
Contact load (max.)

24 V-DC/0.1 A
Rated current [A] 0.027
Dimensions and weights
Dimensions (WxHxD) [mm] 37x53x13
