2-channel transmitter for transmitting two 868 MHz safety contacts

Main image Click to view image in fullscreen

Technical data

Betriebsanleitung-WIRELESSBAND-1-OSE-DE-2020-12
Filetype: PDF

Language: DE

Published at: Dec 9, 2020

Betriebsanleitung-WIRELESSBAND-1-OSE-EN-2020-11
Filetype: PDF

Language: EN

Published at: Nov 26, 2020

Betriebsanleitung-WIRELESSBAND-1-OSE-ES-2020-11
Filetype: PDF

Language: ES

Published at: Nov 26, 2020

Betriebsanleitung-WIRELESSBAND-1-OSE-FR-2020-12
Filetype: PDF

Language: FR

Published at: Dec 9, 2020

for radio transmission of 2 signals (NC/NO/OSE/8.2 kOhm), battery operated, IP67, 868 MHz. For receiver for radio transmission system 868 MHz.

SKU

123739

EAN Code

4062435001126

Quantity

PAU

Quantity

2-channel transmitter for transmitting two 868 MHz safety contacts

Scope of delivery:

Features:

Radio receiver-transmitter system for maximum safety and quick installation
Bi-directional 868 MHz transmission of up to 7 transmitters per receiver and with up to 10 m range
Connection options: OSE + 8.2 kOhm; OSE + NC/NO; 2x 8.2 kOhm; 8.2 kOhm + NC/NO
Up to 2 years battery life (replacement recommended during annual maintenance)
Acoustic signal in case of low battery

2 channel transmitter

Product descriptive data

Connection type Conventional

Number of contacts 2

Inputs

1 input for a safety circuit (NC/NO) or a closing edge fuse (OSE/8.2 kOhm)

1 input for a safety circuit (NC/NO) or a closing edge fuse (8.2 kOhm)

Radio frequency 868 MHz

Channels 2

Interfaces OSE 8.2 kOhm

Protection class IP67

Safety category 2

Application area

Temperature (min./max.) [°C] -20/55

Performance data

Range [m] 10

Electrical data

Battery count 2

battery type AA, 3.6 V (lithium)

Rated current [A] 0.017

Dimensions and weights

Weight [kg] 0.13

Dimensions (WxHxD) [mm] 183x51x36
