Back-up 400 Battery-Backup, 4.5 Ah, in housing, IP65

Battery backup, 4.5 Ah, in IP65 housing. For Comfort 260 (speed), 270 (speed), 280, 360, 370, 380, 390 (plus), Control x.52 and x.82.
SKU
87787
4062434007198
Back-up 400 Battery-Backup, 4.5 Ah, in housing, IP65

Scope of delivery:

  • Battery unit with integrated charge controller
  • Connection cable, 1,000 mm

Features:

  • Weather resistant housing
  • Signaling of charging status and errors via LED
  • Max. 10 cycles period of use within 24 hours at an ambient temperature of +20 °C in conjunction with an operator or a control system with power-saving mode
Back-up 400
Product descriptive data
Connection type Pluggable
Outputs

1 common entrance and exit for loading and supply
Inputs

1 common entrance and exit for loading and supply
Protection class IP65
Application area
Temperature (min./max.) [°C] -15/45
Electrical data
Battery capacity [Ah] 4.5
Operating voltage [V] 24 V-DC
Operating voltage type Direct current
Dimensions and weights
Dimensions (WxHxD) [mm] 120x240x100
Marantec Marienfeld GmbH & Co. KG
Remser Brook 11
33428 Marienfeld



For questions to the manufacturer, please use this Contact form.

Mounting set for back-up 400 in Comfort 861 operator housing
