Ceiling pull switch with slow action, 3.5 m pull rope and 3 m cantilever arm

  • Speditionsartikel
    Speditionsartikel
    Speditionsartikel
with slow action, 3.5 m hauling rope and 3 m cantilever arm. For all Marantec controls and third-party products.
SKU
564275
4062434008300
Ceiling pull switch with slow action, 3.5 m pull rope and 3 m cantilever arm

Scope of delivery:

  • Ceiling pull switch with pull rope, 3,500 mm
  • Cantilever arm, 3.000 mm
  • Cantilever support
  • Installation material

Features:

  • Operation by pulling the pull rope
  • Cantilever arm for wall or lintel installation at a distance from the gate
Ceiling pull switch
Product descriptive data
Connection type Conventional
Number of contacts 2
Contact type 1 NO + 1 NC
Material Aluminum die casting Steel (galvanized)
Protection class IP65
Switching system Snap action
Application area
Temperature (min./max.) [°C] -20/80
Electrical data
Contact load (max.)

400 V-AC/6 A
Dimensions and weights
Rope diameter (max.) [mm] 15
Dimensions (WxHxD) [mm] 40x116x27
Technical data
Download PDF Betriebsanleitung-EM-41-Z-ES-41-Z-DE-EN-FR-IT-PT-2023-06

Filetype: PDF

Language: DE, EN, FR, IT, PT


Published at: Jun 13, 2023 		Preview
