Comfort UN3224 underfloor operator for swing gates up to 3.5 m without encoder
Underfloor operator for swing gates up to 3.5 m: 24 V-DC motor, 250 Nm, 90°, without encoder.
SKU
178384
4062434006016
Note
Product added to cart.
Loading...
Comfort UN3224 underfloor operator for swing gates up to 3.5 m without encoder
Scope of delivery:
- Motor unit without foundation box, pre-wired, 2x1.5 mm² 1,500 mm
Operator – Features:
- Current-dependent obstacle detection - no active closing edge protection necessary (only operators with encoder)
- Intergrated mechanical stops OPEN and CLOSED
- Robust metal gearbox
- Very quiet mechanism
- All mechanical parts protected against weather influences
- Lockable unlocking device
- Compatible with foundation boxes from other manufacturers (additional accessories required)
Comfort UN3224
Product descriptive data
Connection type
Conventional
Continuous sound pressure level (max.) [dB(A)]
70
Encoder
No
Protection class
IP67
Application area
Width gate wing (max.) [m]
3.5
Weight of gate leaf (max.) [kg]
600
Gradient (max.) [%]
0
Temperature (min./max.) [°C]
-20/55
Performance data
Output torque [Nm]
250
Operating mode (duty cycle)
S2 - 8 min
Opening angle (max.) [°]
90
Motor power [kW]
0.12
Electrical data
Operating voltage [V]
24 V-DC
Operating voltage type
Direct current
Motor voltage [V]
24 V-DC
Rated current [A]
5
Dimensions and weights
Weight [kg]
10.8
Dimensions (WxHxD) [mm]
346x160x412
Dimensions (WxHxDmin/Tmax) [mm]
346x160x412/412
