Command 231 4-channel radio code switch, 868 MHz Multi-Bit

4-channel radio code push button with 3 permanent PINs, one temporary PIN, one light button and one protection cover, unidirectional, 868 MHz Multi-Bit For all Marantec controllers and third-party products (in conjunction with corresponding multi-bit receiver)
SKU
69533
4011805049985
76250
Command 231 4-channel radio code switch, 868 MHz Multi-Bit

Scope of delivery:

  • Funk-Codetaster mit 2 Batterien
  • Codierstecker
  • Montagematerial

Features:

  • Operation by entering a 4-digit PIN
  • 3 freely selectable user PINs for free assignment with functions
  • 1 freely selectable temporary user PIN (can be used 3 times)
  • 1 function key for free assignment
  • Signaling by red LED
  • Hinged cover protects the keypad from dirt
Command 231
Product descriptive data
Antenna Integrated
Number of freely programmable keys 1
Color LY7P (metallic titanium gray)
Radio frequency 868 MHz
Radio technology Multi-Bit
Channels 4
Communication direction Unidirectional
Protection class IP54
Radio coding Marantec
Number of permanent PIN codes 3
Number of temporary PIN codes 1
Application area
Temperature (min./max.) [°C] -20/60
Electrical data
Battery count 2
battery type CR2032, 3 V
Dimensions and weights
Dimensions (WxHxD) [mm] 70x198x48
Dimensions (WxHmin./Hmax.xD) [mm] 70x110/198x48
Marantec Marienfeld GmbH & Co. KG
Remser Brook 11
33428 Marienfeld



For questions to the manufacturer, please use this Contact form.

Plug-in lock with 2 keys to secure the lid for Command 231
Command 231 key foil
Command 231 cover flap
