Command 802 RFID transponder system for up to 30 users
RFID transponder system with 30 memory locations, consisting of: Evaluation unit with reader module, IP54, 2 m cable and 3 transponder code cards. For all Marantec controllers and third-party products.
SKU
81076
4062434000304
Note
Product added to cart.
Loading...
Command 802 RFID transponder system for up to 30 users
Scope of delivery:
- Reading module with integrated evaluation unit and 2,000 mm connection cable
- 3 transponder code cards
- Voltage converter from 24 V DC to 12 V DC
- Mounting hardware
Features:
- Contactless operation by holding a transponder in front of it
- Memory for up to 30 transponders
- IMPULSE or ON/OFF function adjustable
- Targeted programming and deletion of individual transponders
Command 802
Product descriptive data
Connection type
Conventional
Number of contacts
1
Number of memory locations
30
Outputs
1 potential-free relay contact (CO)
Inputs
1 potential-free push button input (NO)
Radio frequency
125 kHz
Contact type
1 CO
Interfaces
EM4102
Protection class
IP54
Application area
Temperature (min./max.) [°C]
-10/60
Performance data
Range [m]
0.05
Electrical data
Operating voltage [V]
12 V-AC 12 V-DC
Operating voltage type
Direct current
Power consumption [VA/W/kW]
0.8 W
Contact load (max.)
2,5 A
Rated current [A]
0.06
Dimensions and weights
Dimensions (WxHxD) [mm]
39x75x15
