Command 812 RFID transponder system for up to 2,000 users

RFID transponder system with 2,000 memory locations, consisting of: evaluation unit, IP20, with external reader module, IP54, on 2 m cable, 3 transponder code cards For all Marantec controllers and third-party products
SKU
81077
4062434000311
Command 812 RFID transponder system for up to 2,000 users

Scope of delivery:

  • Evaluation unit
  • Reader module with 2,000 mm connection cable
  • 3 transponder code cards
  • Installation material

Features:

  • Contactless operation by holding a transponder in front of it
  • Generous storage space for up to 2,000 transponders
  • IMPULSE or ON/OFF function adjustable
  • Usable for one or 2 doors (2nd reader module required). Anti-passback function adjustable
  • Inputs for emergency opening and fire alarm
  • Targeted blocking and deletion of individual transponders via keys and display in the absence of the transponders
Command 812
Product descriptive data
Connection type Conventional
Number of contacts 5
Number of memory locations 2,000
Outputs

2 potential-free relays (CO)

2 potential-free outputs (NO) for door monitoring
Inputs

2 potential-free push button inputs (NO)

1 potential-free alarm input (NC)
Radio frequency 125 kHz
Interfaces EM4102
Protection class IP20
Application area
Temperature (min./max.) [°C] -10/60
Performance data
Range [m] 0.05
Electrical data
Operating voltage [V] 24 V-AC 24 V-DC
Operating voltage type Direct current
Power consumption [VA/W/kW] 3.6 W
Contact load (max.)

250 V-AC/3 A
Rated current [A] 0.15
Dimensions and weights
Dimensions (WxHxD) [mm] 100x150x26
