COMRX receiver for radio transmission 868 MHz for 8.2kOhm contact strips

Receiver for radio transmission system 868 MHz for 8.2 kOhm contact strips, up to 8 transmitters can be used simultaneously For all operators. For mechanical or 8.2 kOhm contact strips
SKU
178445
4062434006627
COMRX receiver for radio transmission 868 MHz for 8.2kOhm contact strips

Scope of delivery:

  • Receiver
  • Installation material

Features:

  • Radio receiver-transmitter system for maximum safety and quick installation
  • Bidirectional 868 MHz transmission of up to 8 transmitters per receiver and with up to 20 m range
  • 4 different frequencies to avoid interference
COMRX
Product descriptive data
Connection type Conventional
Number of contacts 2
Outputs

2 potential-free relay contacts (NC)
Inputs

2 test inputs
Radio frequency 868 MHz
Channels 2
Contact type 2 NC
Interfaces 8.2 kOhm
Protection class IP65
Performance data
Range [m] 20
Electrical data
Operating voltage [V] 12 V-AC 12 V-DC 24 V-AC 24 V-DC
Contact load (max.)

42.4 V-AC/0.5 A; 30 V-DC/1 A
Dimensions and weights
Dimensions (WxHxD) [mm] 120x90x30
Marantec Marienfeld GmbH & Co. KG
Remser Brook 11
33428 Marienfeld
