Control 403 Induction loop detector, 2-channel, 230 V-AC
Induction loop detector, 2-channel, 230 V-AC, DIN rail installation For all controls. Can only be used in conjunction with a loop cable
SKU
104057
4062434010617
Item is not available
Note
Product added to cart.
Loading...
Control 403 Induction loop detector, 2-channel, 230 V-AC
Scope of delivery:
- Loop detector
Features:
- Contactless operation by passing over an induction loop
- Directional detection avoids false openings and saves energy costs
- Automatic measurement and display of loop inductance
- Immediate error detection on the illuminated LC display
- Easy programming and simulation possibility
- Max. detectable vehicle speed of 50 km/h (with appropriate loop)
- Mounting on a top-hat rail
Control 403
Product descriptive data
Connection type
Conventional
Number of contacts
3
Contact type
3 CO
Protection class
IP20
Application area
Temperature (min./max.) [°C]
-20/60
Electrical data
Operating voltage [V]
100-240 V/1~
Operating voltage type
Alternating current
Power consumption [VA/W/kW]
2.9 W
Contact load (max.)
Loop output: 240 V-AC/2 A; 30 V-DC/1 A
Alarm output: 40 V-AC/40 V-DC/0.3 A
Loop inductance
Max. 20-1,000 µH, ideally 80-300 µH
Dimensions and weights
Weight [kg]
0.28
Width (pitch units)
1.5
Dimensions (WxHxD) [mm]
22.5x94x88
