Digital 179 Magnetic base antenna with 5 m cable, 868 MHz Multi-Bit

Module antenna with 200 memory locations and magnetic base antenna with 5 m cable, unidirectional, 868 MHz Multi-Bit. For Comfort 260 (accu/speed), 270 (speed), 280, 360, 370, 380, 390 (plus), Control x.52, x.82, VTA and CS 255 AC.
SKU
102053
4062434001226
Digital 179 Magnetic base antenna with 5 m cable, 868 MHz Multi-Bit

Scope of delivery:

  • Module antenna with connection for magnetic base antenna
  • Magnetic base antenna with connection cable, 5.000 mm
  • Installation bracket
  • Installation material
Digital 179
Product descriptive data
Connection type Pluggable
Antenna Rod antenna with magnetic base
Radio frequency 868 MHz
Radio technology Multi-Bit
Channels 1
Communication direction Unidirectional
Protection class IP00
Radio coding Marantec
Application area
Temperature (min./max.) [°C] -20/60
Electrical data
Operating voltage [V] 5 V-DC
Rated current [A] 0.002
Dimensions and weights
Dimensions (WxHxD) [mm] 23x7.7x48.4
Marantec Marienfeld GmbH & Co. KG
Remser Brook 11
33428 Marienfeld
