Digital 361 1-channel flush-mounted receiver 230 V, 868 MHz Multi-Bit

1-channel flush-mounted receiver with one potential relay, 230 V, unidirectional, 868 MHz Multi-Bit. For all Marantec controllers and third-party products.
SKU
65654
4011805049169
Digital 361 1-channel flush-mounted receiver 230 V, 868 MHz Multi-Bit

Scope of delivery:

  • Flush-mounted receiver

Features:

  • 1 channel for free assignment
  • 1 potential-loaded relay contact for direct switching of an electrical device, e.g. outdoor lamp
  • ON/OFF function
  • Compact size
Digital 361
Product descriptive data
Connection type Conventional
Antenna Wire antenna
Number of memory locations 1
Outputs

1 potential-loaded relay contact (NO)
Color RAL 7011
Radio frequency 868 MHz
Radio technology Multi-Bit
Channels 1
Communication direction Unidirectional
Contact type 1 NO
Protection class IP40
Radio coding Marantec
Application area
Temperature (min./max.) [°C] -20/60
Electrical data
Operating voltage [V] 230 V/1~
Operating voltage type Alternating current
Power consumption [VA/W/kW] 6.9 W
Contact load (max.)

230 V/6 A/1,380 VA
Rated current [A] 0.03
Dimensions and weights
Dimensions (WxHxD) [mm] 45x45x25
Marantec Marienfeld GmbH & Co. KG
Remser Brook 11
33428 Marienfeld



For questions to the manufacturer, please use this Contact form.
