Digital 525 4-channel radio code switch with 3 PINs, 868 MHz bi.linked

4-channel radio code push button with 3 permanent PINs, one temporary PIN and one light button, unidirectional, 868 MHz bi.linked For all Marantec controllers and third-party products (in conjunction with corresponding bi.linked receiver)
SKU
101149
4062434001028
Digital 525 4-channel radio code switch with 3 PINs, 868 MHz bi.linked

Scope of delivery:

  • Funk-Codetaster mit 2 Batterien
  • Montagematerial

Features:

  • Operation by entering a 4-digit PIN
  • 3 freely selectable user PINs for free assignment with functions
  • 1 freely selectable temporary user PIN (can be used 3 times)
  • 1 changeable master PIN for management
  • 1 function key for free assignment
  • Signaling by red LED
  • High security through 128-bit AES-encrypted radio transmission and constantly changing radio code (rolling code method)
Digital 525
Product descriptive data
Antenna Integrated
Number of freely programmable keys 1
Color RAL 9006
Radio frequency 868 MHz
Radio technology bi.linked
Channels 4
Communication direction Unidirectional
Protection class IP54
Radio coding Marantec
Number of permanent PIN codes 3
Number of temporary PIN codes 1
Application area
Temperature (min./max.) [°C] -20/60
Electrical data
Battery count 2
battery type AAA, 1.5 V
Dimensions and weights
Dimensions (WxHxD) [mm] 80x102x35
Marantec Marienfeld GmbH & Co. KG
Remser Brook 11
33428 Marienfeld



For questions to the manufacturer, please use this Contact form.
