Digital 941 magnetic base antenna with 5 m cable, 868 MHz bi.linked

Module receiver with 200 memory locations and magnetic base antenna with 5 m cable, bidirectional, 868 MHz bi.linked For Comfort 260 (accu/speed), 270 (speed), 280, 360, 370, 380 and 390 (plus) from control box R10. For Control x.52, x.82, CS 255 AC and VTA
SKU
101185
4062434001134
Digital 941 magnetic base antenna with 5 m cable, 868 MHz bi.linked

Scope of delivery:

  • Module antenna with connection for magnetic base antenna
  • Magnetic base antenna with connection cable, 5.000 mm
  • Installation bracket
  • Installation material
Digital 941
Product descriptive data
Connection type Pluggable
Antenna Rod antenna with magnetic base
Number of memory locations 200
Radio frequency 868 MHz
Radio technology bi.linked
Channels 256
Communication direction Bidirectional
Protection class IP00
Radio coding Marantec
Application area
Temperature (min./max.) [°C] -20/60
Electrical data
Operating voltage [V] 5 V-DC
Rated current [A] 0.002
Dimensions and weights
Dimensions (WxHxD) [mm] 23x7.7x48.4
Marantec Marienfeld GmbH & Co. KG
Remser Brook 11
33428 Marienfeld



For questions to the manufacturer, please use this Contact form.
