EM 171 extension module with two programmable relays

MS-Bus extension module with 2 programmable relays, DIN rail installation, with 0.14 m MS-Bus cable. For Comfort 260 (speed), 270 (speed), 280, 360, 370, 380, 390 (plus), Control x.52, x.82 and VTA.
SKU
96658
4062434006849
EM 171 extension module with two programmable relays

Scope of delivery:

  • Extension module
  • Connection cable MS bus RJ14, 140 mm

Features:

  • 2 programmable potential-free relay outputs (changeover contacts)
  • Status and diagnostic messages via LED
  • Installation on a top-hat rail
EM 171
Product descriptive data
Connection type Pluggable
Outputs

2 programmable potential-free relay outputs (CO)
Contact type 2 CO
Interfaces MS bus (RJ14 connector)
Protection class IP00
Application area
Temperature (min./max.) [°C] -20/60
Electrical data
Operating voltage [V] 24 V-DC
Operating voltage type Direct current
Contact load (max.)

230 V/6 A
Dimensions and weights
Width (pitch units) 2.5
Dimensions (WxHxD) [mm] 45x126x48
