EM 181 extension module for system photoelectric sensor and Opto 100

MS-Bus extension module with connection for light barrier and opto-sensors Opto 100 with system cabling, top hat rail installation, with 0.14 m MS-Bus cable. For Comfort 260 (speed), 270 (speed), 280, 360, 370, 380, 390 (plus) and VTA.
SKU
90588
4062434007075
EM 181 extension module for system photoelectric sensor and Opto 100

Scope of delivery:

  • Extension module
  • Connection cable MS bus RJ14, 140 mm

Features:

  • 1 programmable input for light barriers with system wiring
  • 1 programmable input for OPTO 100 opto-sensors with system wiring
  • Status and diagnostic messages via LED
  • Installation on a top-hat rail
EM 181
Product descriptive data
Connection type Pluggable
Inputs

1 programmable input for photoelectric sensors with system wiring

1 programmable input for opto-sensors OPTO 100 with system wiring
Interfaces MS bus (RJ14 connector)
Protection class IP00
Application area
Temperature (min./max.) [°C] -20/60
Electrical data
Operating voltage [V] 24 V-DC
Operating voltage type Direct current
Dimensions and weights
Width (pitch units) 2.5
Dimensions (WxHxD) [mm] 45x126x48
