Ex light barrier reflex in housing, 8 m, 2-wire, for zone 1/2

Ex reflex light barrier, 8 m, 2-wire, IP67, including switching amplifier NE with signal conditioning instrument, in housing, for zones 1 and 2.
SKU
141705
4062434015247
Ex light barrier reflex in housing, 8 m, 2-wire, for zone 1/2

Scope of delivery:

  • Reflex light barrier
  • Reflector 84x84x8,5 mm
  • Switching amplifier in housing
Ex light barrier reflex
Product descriptive data
Connection type Conventional
Material Zinc die casting
Protection class IP67
Application area
ATEX assembly area EX area
ATEX zone (gas) Zone 1 Zone 2
ATEX zone (dust) Zone 21 Zone 22
Temperature (min./max.) [°C] -20/60
Performance data
Range [m] 22
Electrical data
Operating voltage [V] 5-15.5 V-DC
Power consumption [VA/W/kW] 0.1 W
Rated current [A] 0.05
Dimensions and weights
Weight [kg] 0.33
Dimensions (WxHxD) [mm] 27x87.5x65
