F receiver with 0.4 m cable, plug-in, OSE

0.4 m cable, pluggable, OSE. For controls with connection for OSE opto-sensors. For door leaf junction boxes with connection for pluggable safety elements.
SKU
119200
4062435001256
F receiver with 0.4 m cable, plug-in, OSE

Scope of delivery:

  • F photoelectric sensor receiver with 400 mm cable and connector (Molex)
F receiver pluggable
Product descriptive data
Connection type Pluggable
Interfaces OSE
Protection class IP68
Application area
Temperature (min./max.) [°C] -20/75
Performance data
Range [m] 10
Electrical data
Operating voltage [V] 4-28 V-DC
Dimensions and weights
Diameter [mm] 11
Weight [kg] 0.03
Cable length [m] 0.4
