Light 201 LED lighting system with radio receiver 868 MHz bi.linked

LED lighting system for garages, consisting of 2 magnetic LED strips, each 1,5 m long, connection unit 230 V-AC with integrated radio receiver 868 MHz bi.linked. For retractable up-and-over doors and sectional doors.
SKU
177521
4062434012802
Light 201 LED lighting system with radio receiver 868 MHz bi.linked

Scope of delivery:

  • Connection box with integrated power supply unit, radio receiver 868 MHz bi.linked and connection cable with Schuko plug type F, 1,000 mm
  • 2 potted LED strips, 1,500 mm long, with integrated magnets and connecting cable, 3,000 mm
  • Installation material

Features:

  • LED lighting system for additional light in the garage
  • LED strip with integrated magnets for installation on the right and left door track
  • Pluggable cable connections simplify assembly
  • Connection box with integrated radio receiver
  • Previously unused hand transmitter or wall transmitter buttons can be programmed into the radio receiver to switch the light on and off
Light 201
Product descriptive data
Number of memory locations 100
Color RAL 9003
Color temperature [K] 4,000
Radio frequency 868 MHz
Radio technology bi.linked
Illuminant LED
Luminous flux [lm] 4,400
Protection class IP20
Radio coding Marantec
Electrical data
Operating voltage [V] 230 V/1~
Operating voltage type Alternating current
Power consumption [VA/W/kW] 21.5 W
Dimensions and weights
Dimensions (WxHxD) [mm] 134x178x46
Marantec Marienfeld GmbH & Co. KG
Remser Brook 11
33428 Marienfeld



For questions to the manufacturer, please use this Contact form.
