Lock 720 electric lock for sectional doors, installation on the track

Electric lock for sectional doors, installation on the running rail. For Comfort 260 (speed), 270 (speed), 280, 360, 370, 380 and 390 (plus).
SKU
160432
4062434015049
Lock 720 electric lock for sectional doors, installation on the track

Scope of delivery:

  • Electric lock with emergency release
  • Expansion circuit board EP 163
  • Board holder
  • Connection cable, 10.000 mm
  • Installation material

Features:

  • Electric lock for additional security of a closed sectional door
  • A pin blocks the movement of the gate to prevent it from sliding open. As soon as the operator starts, the pin is retracted and held for the duration of the travel
  • The "power to unlock" principle saves energy, as the electric lock is only supplied with power during gate travel. Furthermore, the gate is still additionally secured even during a power failure
  • A mechanical release enables the unlocking of the bolt
Lock 720
Product descriptive data
Connection type Pluggable
Protection class IP20
Electrical data
Operating voltage [V] 24 V-DC
Power consumption [VA/W/kW] 29 W
Rated current [A] 1.2
Dimensions and weights
Dimensions (WxHxD) [mm] 28x205x65
