LS22 throughbeam photoelectric sensor with 25 m range, 4-wire, without cable
Through beam photoelectric sensor with 25 m range, 24 V-DC, 4-wire, IP54, without cable. For controls with connection for 4-wire light barriers.
SKU
178435
4062434006528
Note
Product added to cart.
Loading...
LS22 throughbeam photoelectric sensor with 25 m range, 4-wire, without cable
Scope of delivery:
- Light barrier transmitter
- Light barrier receiver
- Installation material
Features:
- Suitable for installation in the CH-51N and CH-101N pedestals
- Optical safety device to protect against personal injury and damage to property
LS22
Product descriptive data
Connection type
Conventional
Outputs
1 potential-free relay contact (CO)
Interfaces
4-wire
Protection class
IP54
Application area
Temperature (min./max.) [°C]
-20/55
Performance data
Range [m]
25
Range (min./max.) [m]
0/25
Electrical data
Operating voltage [V]
12-24 V-AC 12-35 V-DC
Contact load (max.)
24 V-DC/1 A
Rated current [A]
0.037
Dimensions and weights
Dimensions (WxHxD) [mm]
30x90x28
