Magic Switch radar push-button, multicolored LED, flush-mounted, IP65, white
Radar push button, multicolor LED signaling, flush mount, 12-24 V-AC/DC, IP65, white For all Marantec controls and third-party products
SKU
185303
4062434013700
Item is not available
Note
Product added to cart.
Loading...
Magic Switch radar push-button, multicolored LED, flush-mounted, IP65, white
Scope of delivery:
- Motion sensor
Features:
- Contactless opening of doors and gates
- A hand movement in front of the pushbutton switches an integrated relay
- IMPULSE or ON/OFF function adjustable
- Multicolor LED ring for orientation and acknowledgement of a command (colors adjustable via DIP switch)
- Non-contact and hygienic: the antimicrobial front limits the spread of germs, bacteria and fungi
- No collision damage due to flush mounting
Magic Switch
Product descriptive data
Connection type
Conventional
Outputs
1 potential-free relay contact (CO)
Color
White
Radio frequency
2.4 GHz
Contact type
1 CO
Protection class
IP65
Sensoren
Radar
Application area
Temperature (min./max.) [°C]
-20/55
Performance data
Range [m]
0.6
Electrical data
Operating voltage [V]
12-24 V-AC 12-24 V-DC
Operating voltage type
Alternating current or direct current
Power consumption [VA/W/kW]
1.5 W
Contact load (max.)
42 V-AC/DC/0.1 A
Dimensions and weights
Dimensions (WxHxD) [mm]
80x80x8
