Protect-Opto 603 Advancing photocell DUO for garage door openers
DUO leading photoelectric sensor for garage door openers, consisting of DUO opto-sensor set with mounting brackets, 2 door leaf junction boxes, 10 m door leaf connecting cable, spiral cable, junction box, 10 m connecting cable and EP 144 expansion board. For Comfort 260 (speed), 270 (speed), 280, 360, 370, 380 and 390.
SKU
177766
4062434014769
Item is not available
Protect-Opto 603 Advancing photocell DUO for garage door openers
Scope of delivery:
- F photoelectric sensor DUO transmitter with 1,000 mm cable
- F-Light barrier DUO receiver with 1.000 mm cable
- 2 installation brackets and 2 floor installation plates
- EP 144 expansion board
- Junction box
- Connection cable 7x0,25 mm², 10.000 mm
- Spiral cable 5x0,25 mm², 1.600 mm uncoiled
- 2 gate leaf junction boxes with board OSE/8,2 kOhm
- Gate leaf connecting cable 7x0,25 mm², 10.000 mm
- Installation material
Protect-Opto 602
Product descriptive data
Connection type
Conventional
Protection class
IP54
Application area
Temperature (min./max.) [°C]
-10/55
Performance data
Range [m]
6
Electrical data
Operating voltage [V]
4-28 V-DC
Power consumption [VA/W/kW]
0.12 W
Dimensions and weights
Weight [kg]
1.9
Dimensions (WxHxD) [mm]
52x331x153
Marantec Marienfeld GmbH & Co. KG
Remser Brook 11
33428 Marienfeld
Remser Brook 11
33428 Marienfeld
For questions to the manufacturer, please use this Contact form.
