Protect-Switch 190 door leaf junction box for wicket door contacts
Door leaf junction box for wicket door contacts for garage door openers, consisting of door leaf junction box IP54, spiral cable 5x0,25 mm², 1.600 mm uncoiled and 800-3.200 mm coiled length, pluggable; junction box and 10.000 mm connection cable. For Comfort 260 (speed), 270 (speed), 280, 360, 370, 380 and 390.
SKU
177767
4062434014752
152839
Item is not available
Note
Product added to cart.
Loading...
Protect-Switch 190 door leaf junction box for wicket door contacts
Scope of delivery:
- Spiral cable 5x0,25 mm² with cable glands, connection terminals for the control and plug for the door leaf connection box, 1.600 mm uncoiled/800-3.200 mm coiled length
- Bracket for spiral cable
- Gate connection box with board OSE/8,2 kOhm
- Junction box
- Connecting cable 2-core, 10.000 mm
- Installation material
Spiral cable 5x0.25 mm² - 1,600 mm
Product descriptive data
Wire cross-section [mm²]
0.25
Cable entry control housing
CS housing
Dimensions and weights
Weight [kg]
0.55
Length uncoiled - control [mm]
1,600
Turning length extended [mm]
3,200
Turning length retracted [mm]
800
