Retro-reflective photoelectric sensor 24-240 V-AC/-DC, 10 m range with mounting bracket

Unsere Parksysteme sind flexibel anpassbar. Sie sind nicht beschränkt auf eine Zufahrt, auch nicht auf die Zufahrtsregelung über Schranken. Sie können zusätzlich mit Rolltoren gesicherte Tiefgaragen ausstatten und verwalten. For controls with connection for 4-wire light barriers
SKU
98692
4062435001485
Retro-reflective photoelectric sensor 24-240 V-AC/-DC, 10 m range with mounting bracket

Scope of delivery:

  • Light barrier transmitter/receiver
  • Reflector 80 mm
  • Installation bracket

Features:

  • The reflector saves the laying of a cable from the control to the opposite side of the gate
  • Optical safety device to protect against personal injury and damage to property
Reflex light barrier 24-240 V-AC/-DC
Product descriptive data
Connection type Conventional
Outputs

1 potential-free relay contact (CO)
Interfaces 4-wire
Protection class IP66
Application area
Temperature (min./max.) [°C] -25/55
Performance data
Range [m] 10
Range (min./max.) [m] 0/10
Electrical data
Operating voltage [V] 24-240 V-AC/-DC
Power consumption [VA/W/kW] 5 VA
Contact load (max.)

3 A (240 V-AC), 3 A (30 V-DC)
Dimensions and weights
Weight [kg] 0.22
Dimensions (WxHxD) [mm] 63x75x24
