Special 305 Emergency release for swing/sectional doors with 0.7 m Bowden cable

Emergency release for swing and sectional doors, 13 mm cylinder lock with 2 keys and 0.7 m Bowden cable. For opener rails SZ and swing gate operators Comfort 515 (L) and 516 (L). For sectional doors, side sectional doors and swing gates.
SKU
182026
4062434012550
Special 305 Emergency release for swing/sectional doors with 0.7 m Bowden cable

Scope of delivery:

  • Cylinder lock with protection cap and 2 keys
  • Bowden cable, 700 mm
  • Installation material

Features:

  • The mortise lock is retrofitted in the door and connected to the release of the operator system via the Bowden cable
  • Pulling out the cylinder mechanically unlocks the operator system, e.g. in the event of a power failure
  • Cylinder lock with standard cylinder
Special 305
Product descriptive data
Material Steel (galvanized)
Installation type Screw on
Application area
Installationarea Gate
Dimensions and weights
Diameter drilled hole [mm] 13
Bowden cable length [m] 0.7
Dimensions (WxHxD) [mm] 20x20x56
Marantec Marienfeld GmbH & Co. KG
Remser Brook 11
33428 Marienfeld
