Special 613-2 retro-reflective photoelectric sensor, 8 m range, 2-wire, 7.5 m cable

Unsere Parksysteme sind flexibel anpassbar. Sie sind nicht beschränkt auf eine Zufahrt, auch nicht auf die Zufahrtsregelung über Schranken. Sie können zusätzlich mit Rolltoren gesicherte Tiefgaragen ausstatten und verwalten.. For controls with connection for 2-wire light barriers.
SKU
85295
4062434007341
Special 613-2 retro-reflective photoelectric sensor, 8 m range, 2-wire, 7.5 m cable

Scope of delivery:

  • Light barrier transmitter/receiver
  • Reflector
  • Connecting cable, 7,500 mm
  • Installation material

Features:

  • 2-wire technology: supply, signal and testing via only 2 polarity reversal protected and connectable wires
  • The reflector saves the laying of a cable from the control to the opposite side of the gate
  • Optical safety device to protect against personal injury and damage to property
Special 613-2
Product descriptive data
Connection type Conventional
Interfaces 2-wire
Protection class IP65
Performance data
Range [m] 8
Range (min./max.) [m] 1/8
Electrical data
Operating voltage [V] 24 V-DC
Dimensions and weights
Cable length [m] 7.5
Dimensions (WxHxD) [mm] 59x96x55
Marantec Marienfeld GmbH & Co. KG
Remser Brook 11
33428 Marienfeld
