Comfort ST5024E Drive for swing gates up to 5.0 m with encoder
Operator for swing gates up to 5.0 m: 24 V DC motor, 1,400 N, 2.7 cm/s, 122°, with encoder.
SKU
178377
4062434005941
Item is not available
Note
Product added to cart.
Loading...
Comfort ST5024E Drive for swing gates up to 5.0 m with encoder
Scope of delivery:
- Motor unit, pre-wired, 500 mm (2x1.5 and 3x0.5 mm² required)
- Gate and angle bracket for welding
Operator – Features:
- Current-dependent obstacle detection - no active closing edge protection necessary
- Built-in encoder for maximum precision
- Mechanical end stop in end position CLOSED necessary
- Mechanical stop in OPEN for end position control
- Driver on spindle with double bearings for maximum smooth running
- Robust metal gearbox
- Very quiet mechanics
- All mechanical parts protected against weather influences
- Sturdy and UV-resistant plastic housing
- Gate and pillar angle for easy motor mounting
- Lockable unlocking device
Comfort ST5024E
Product descriptive data
Connection type
Conventional
Continuous sound pressure level (max.) [dB(A)]
70
Encoder
Yes
Protection class
IP44
Application area
Width gate wing (max.) [m]
5
Weight of gate leaf (max.) [kg]
600
Height gate wing (max.) [m]
2
Gradient (max.) [%]
0
Temperature (min./max.) [°C]
-20/55
Performance data
Operating mode (duty cycle)
S2 - 8 min
Running speed (max.) [cm/s]
2.7
Opening angle (max.) [°]
122
Push and pull force (max.) [N]
1,400
Motor power [kW]
0.12
Electrical data
Operating voltage [V]
24 V-DC
Operating voltage type
Direct current
Motor voltage [V]
24 V-DC
Rated current [A]
5
Dimensions and weights
Weight [kg]
9.5
Movement stroke (max.) [mm]
490
Dimensions (WxHxD) [mm]
108x110x995
Dimensions (WxHxDmin/Tmax) [mm]
108x110x995/995
