FALCON radar motion detector, 3.5-7.0 m mounting height, with 10 m cable
Radar motion detector, 3.5-7.0 m installation height, IP65 with 10 m cable For all Marantec controls and third-party products
SKU
122432
4062434009321
Item is not available
Note
Product added to cart.
Loading...
FALCON radar motion detector, 3.5-7.0 m mounting height, with 10 m cable
Scope of delivery:
- Motion sensor
- Connection cable, 10.000 mm
Features:
- Non-contact opening of gates by entering the detection area
- Directional detection avoids false openings and saves energy costs
- Capture filter to distinguish between people and vehicles
FALCON
Product descriptive data
Connection type
Conventional
Outputs
1 potential-free relay contact (CO)
Color
Black
Radio frequency
2.4 GHz
Contact type
1 CO
Protection class
IP65
Sensoren
Radar
Application area
Installation height (min./max.) [m]
3.5/7
Temperature (min./max.) [°C]
-30/60
Performance data
Detection field radar (WxL max.) [m]
4x5
Electrical data
Operating voltage [V]
12-24 V-AC 12-24 V-DC
Operating voltage type
Alternating current or direct current
Power consumption [VA/W/kW]
2 W
Contact load (max.)
60 VA/30 W
Dimensions and weights
Dimensions (WxHxD) [mm]
127x102x96
Marantec Marienfeld GmbH & Co. KG
Remser Brook 11
33428 Marienfeld
Remser Brook 11
33428 Marienfeld
For questions to the manufacturer, please use this Contact form.
