FALCON XL radar motion detector, 2.0-3.5 m mounting height, with 10 m cable

Radar motion detector, 2.0-3.5 m installation height, IP65, with 10 m cable. For all Marantec controls and third-party products.
SKU
159708
4062434008744
FALCON XL radar motion detector, 2.0-3.5 m mounting height, with 10 m cable

Scope of delivery:

  • Motion sensor
  • Connection cable, 10.000 mm

Features:

  • Non-contact opening of doors by entering the detection area
  • Directional detection avoids false openings and saves energy costs
  • Capture filter to distinguish between people and vehicles
FALCON XL
Product descriptive data
Connection type Conventional
Outputs

1 potential-free relay contact (CO)
Color Black
Radio frequency 2.4 GHz
Contact type 1 CO
Protection class IP65
Sensoren Radar
Application area
Installation height (min./max.) [m] 2/3.5
Temperature (min./max.) [°C] -30/60
Performance data
Detection field radar (WxL max.) [m] 4x2
Electrical data
Operating voltage [V] 12-24 V-AC 12-24 V-DC
Operating voltage type Alternating current or direct current
Power consumption [VA/W/kW] 2 W
Contact load (max.)

60 VA/30 W
Dimensions and weights
Dimensions (WxHxD) [mm] 127x102x96
