LZR-WIDESCAN laser scanner for vertical doors, 2-10 m mounting height
Laser motion detector and presence sensor, 2.0-10.0 m installation height, IP65, with 10 m cable For all Marantec controls and third-party products. An additional power supply unit for voltage supply is required for many controls
SKU
160034
4062434008713
Item is not available
Note
Product added to cart.
Loading...
LZR-WIDESCAN laser scanner for vertical doors, 2-10 m mounting height
Scope of delivery:
- Motion and presence sensor
- Connection cable, 10,000 mm
Features:
- Non-contact opening of gates by entering the detection area
- Contactless protection of gate, persons or objects by presence detection in the vestibule of the gate
- Directional detection avoids false openings and saves energy costs
- Capture filter to distinguish between people and vehicles
- 3 virtual pull switches programmable to open the gate
- Depending on the size of the detected object, different opening heights can be controlled to optimize energy costs
- Programming of functions and diagnostics via an integrated LC display or simply via Bluetooth with the smartphone app
LZR-WIDESCAN
Product descriptive data
Connection type
Conventional
Outputs
3 potential-free relay contacts (1 CO, 1 NO, 1 NC)
Inputs
1 Test input
Color
Black
Protection class
IP65
Sensoren
Laser
Wave length [nm]
905
Application area
Temperature (min./max.) [°C]
-30/60
Performance data
Detection field laser (WxL max.) [m]
10x10
Electrical data
Operating voltage [V]
12-24 V-AC 12-30 V-DC
Operating voltage type
Alternating current or direct current
Power consumption [VA/W/kW]
15 W
Contact load (max.)
48 VA/30 W
Dimensions and weights
Dimensions (WxHxD) [mm]
150x200x100
