SZ 11 2-piece drive rail Profile length 3,080 mm Thickness 1.2 mm

Opener rail for garage door openers, 3.08 m profile length, 1.2 mm thickness, ball bearing, toothed belt, 2-piece. For Comfort 260 (accu/speed), 270 (speed), 280, 360, 370, 380 and 390 (plus).
SKU
177214
EAN Code
4062434014813

Prices are only visible after login.

SZ 11 2-piece drive rail Profile length 3,080 mm Thickness 1.2 mm

Scope of delivery:

  • 2-part opener rail with rail connector, pre-assembled ready for installation
SZ 11
Product descriptive data
Operator means Toothed belt
Bearing Ball bearing
Division 2-piece
Application area
Height overhead doors (max.) [m] 2.5
Height of sectional doors with normal fitting (max.) [m] 2.25
Height of sectional doors with low lintel fitting (max.) [m] 2.125
Height of sectional doors with tension springs (max.) [m] 2.125
Dimensions and weights
Weight [kg] 7.8
Material thickness [mm] 1.2
Movement stroke [mm] 2,460
Profile length [mm] 3,080
Marantec Marienfeld GmbH & Co. KG
Remser Brook 11
33428 Marienfeld



For questions to the manufacturer, please use this Contact form.
