Extension board with 3 relays for OPEN/CLOSE/light, in housing, IP65

Extension circuit board with 3 relays for OPEN/CLOSE/Light, system wiring, in IP65 housing For Comfort 260 (speed), 270 (speed), 280, 360, 370, 380 and 390. Can only be used in conjunction with EP 141 expansion circuit board
SKU
85236
4062434007365
Extension board with 3 relays for OPEN/CLOSE/light, in housing, IP65

Scope of delivery:

  • Relay retrofit kit in housing
  • System cable, 2,100 mm
  • Installation material

Features:

  • 3 potential-free relay contacts for end position signals OPEN, CLOSED and external lighting
  • 1 input for Marantec operating elements with system wiring
Relay retrofit kit
Product descriptive data
Connection type Pluggable
Outputs

2 potential-free relay contacts for end position messages (CO)

1 potential-free relay contact for lighting (NO)
Inputs

1 input for control elements with system wiring
Contact type 2 CO + 1 NO
Interfaces System cabling (RJ11 connector)
Protection class IP65
Electrical data
Operating voltage [V] 24 V-DC
Operating voltage type Direct current
Contact load (max.)

250 V/60 W
Dimensions and weights
Dimensions (WxHxD) [mm] 200x60x120
